TC74VHC574FK(EL,K)
IC FF D-TYPE SNGL 8BIT 20VSSOPManufacturer: Toshiba Semiconductor and Storage
Categories: Flip Flops
Quality Control: Learn More
Toshiba Semiconductor and Storage TC74VHC574FK-EL-K- is an 8-bit, single D-type flip-flop from the TC74VHC series. This device features tri-state, non-inverted outputs and operates on a voltage supply range of 2V to 5.5V. With a maximum clock frequency of 115 MHz and a typical propagation delay of 10.6ns at 5V with a 50pF load, it is suitable for high-speed digital applications. The component offers 8mA output drive capability for both high and low states and a quiescent current of 40 µA. It is housed in a 20-VSSOP package, specifically the 20-VFSOP (0.118", 3.00mm Width) variant, and is supplied on tape and reel. This flip-flop is commonly utilized in consumer electronics, industrial control systems, and data acquisition equipment.
Additional Information
Series: TC74VHCRoHS Status: RoHS CompliantManufacturer Lead Time: 52 week(s)Product Status: Not For New DesignsPackaging: Tape & Reel (TR)Download Free CAD Model:&lbl=1&lbc=000000&q3=1)
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 20-VFSOP (0.118"", 3.00mm Width) |
| Output Type | Tri-State, Non-Inverted |
| Mounting Type | Surface Mount |
| Number of Elements | 1 |
| Function | Standard |
| Type | D-Type |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply | 2V ~ 5.5V |
| Current - Quiescent (Iq) | 40 µA |
| Current - Output High, Low | 8mA, 8mA |
| Trigger Type | Positive Edge |
| Clock Frequency | 115 MHz |
| Input Capacitance | 4 pF |
| Supplier Device Package | 20-VSSOP |
| Max Propagation Delay @ V, Max CL | 10.6ns @ 5V, 50pF |
| Grade | - |
| Number of Bits per Element | 8 |
| Qualification | - |
