TXB0104RGYRG4
IC TRANSLTR BIDIRECTIONAL 14VQFNManufacturer: Texas Instruments
Categories: Translators, Level Shifters
Quality Control: Learn More
The Texas Instruments TXB0104RGYRG4 is a robust voltage level translator designed for seamless signal translation between diverse voltage domains. This component features 4 bidirectional channels, enabling efficient data flow in both directions at speeds up to 100Mbps. Its auto-direction sensing capability simplifies design by automatically determining signal direction, eliminating the need for external control signals. The TXB0104RGYRG4 operates with VCCA ranging from 1.2V to 3.6V and VCCB from 1.65V to 5.5V, accommodating a wide array of system voltage requirements. Packaged in a compact 14-VQFN (3.5x3.5) with exposed pad for enhanced thermal performance, it is suitable for surface-mount applications. This device finds utility in automotive, industrial automation, and consumer electronics, where interfacing different logic levels is critical. The output type is Tri-State, Non-Inverted. Operating temperature range is -40°C to 85°C (TA).
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Auto-Direction Sensing |
| Packaging | Tape & Reel (TR) |
| Package / Case | 14-VFQFN Exposed Pad |
| Output Type | Tri-State, Non-Inverted |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Data Rate | 100Mbps |
| Supplier Device Package | 14-VQFN (3.5x3.5) |
| Channel Type | Bidirectional |
| Output Signal | - |
| Translator Type | Voltage Level |
| Channels per Circuit | 4 |
| Voltage - VCCA | 1.2 V ~ 3.6 V |
| Voltage - VCCB | 1.65 V ~ 5.5 V |
| Input Signal | - |
| Number of Circuits | 1 |
