SN74LVCC3245ADBRE4
IC TRANSLTR BIDIRECTIONAL 24SSOPManufacturer: Texas Instruments
Categories: Translators, Level Shifters
Quality Control: Learn More
Texas Instruments 74LVCC series SN74LVCC3245ADBRE4 is an 8-bit, dual-supply bus transceiver featuring bidirectional voltage-level translation. This single-circuit device operates with VCCA ranging from 2.3V to 3.6V and VCCB from 3V to 5.5V, facilitating seamless interface between different voltage domains. The SN74LVCC3245ADBRE4 offers eight channels with tri-state, non-inverted outputs and supports bidirectional data flow. Packaged in a 24-SSOP (0.209", 5.30mm Width) on tape and reel, this component is suitable for surface mount applications. Its design makes it valuable in telecommunications, consumer electronics, and industrial automation where voltage level compatibility is critical. The operating temperature range is -40°C to 85°C (TA).
Additional Information
Series: 74LVCCRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 24-SSOP (0.209"", 5.30mm Width) |
| Output Type | Tri-State, Non-Inverted |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Data Rate | - |
| Supplier Device Package | 24-SSOP |
| Channel Type | Bidirectional |
| Output Signal | - |
| Translator Type | Voltage Level |
| Channels per Circuit | 8 |
| Voltage - VCCA | 2.3 V ~ 3.6 V |
| Voltage - VCCB | 3 V ~ 5.5 V |
| Input Signal | - |
| Number of Circuits | 1 |
