SN74AVCH1T45YEPR
IC TRANSLTR BIDIRECTIONAL 6DSBGAManufacturer: Texas Instruments
Categories: Translators, Level Shifters
Quality Control: Learn More
Texas Instruments SN74AVCH1T45YEPR is a single-circuit, single-channel bidirectional voltage level translator. This device supports a 500Mbps data rate and operates across a wide VCCA and VCCB range of 1.2V to 3.6V. The 74AVCH series component features tri-state, non-inverted outputs and is housed in a compact 6-DSBGA package, suitable for surface mounting. Its design is optimized for applications requiring seamless signal translation between different voltage domains, commonly found in automotive, industrial, and consumer electronics. The SN74AVCH1T45YEPR is supplied on tape and reel for efficient automated assembly.
Additional Information
Series: 74AVCHRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 6-XFBGA, DSBGA |
| Output Type | Tri-State, Non-Inverted |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Data Rate | 500Mbps |
| Supplier Device Package | 6-DSBGA |
| Channel Type | Bidirectional |
| Output Signal | - |
| Translator Type | Voltage Level |
| Channels per Circuit | 1 |
| Voltage - VCCA | 1.2 V ~ 3.6 V |
| Voltage - VCCB | 1.2 V ~ 3.6 V |
| Input Signal | - |
| Number of Circuits | 1 |
