74AVCAH164245ZQLR
IC TRANSLTR BIDIRECTIONAL 56BGAManufacturer: Texas Instruments
Categories: Translators, Level Shifters
Quality Control: Learn More
Texas Instruments 74AVCAH164245ZQLR is a dual-circuit, 8-channel, bidirectional voltage level translator. This device features 56-BGA Microstar Junior (7x4.5) packaging suitable for surface mounting. Each circuit supports 8 channels with Tri-State, Non-Inverted output signaling. The VCCA and VCCB supply voltages can range from 1.4V to 3.6V, facilitating seamless voltage translation between diverse logic families. This component is designed for applications requiring flexible signal level management, commonly found in industrial automation, automotive systems, and advanced computing platforms. The device operates within an ambient temperature range of -40°C to 85°C and is supplied on a tape and reel.
Additional Information
Series: 74AVCAHRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 56-VFBGA |
| Output Type | Tri-State, Non-Inverted |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Data Rate | - |
| Supplier Device Package | 56-BGA Microstar Junior (7x4.5) |
| Channel Type | Bidirectional |
| Output Signal | - |
| Translator Type | Voltage Level |
| Channels per Circuit | 8 |
| Voltage - VCCA | 1.4 V ~ 3.6 V |
| Voltage - VCCB | 1.4 V ~ 3.6 V |
| Input Signal | - |
| Number of Circuits | 2 |
