SN74ABT841ADWG4
IC D-TYPE LATCH SGL 3-ST 24SOICManufacturer: Texas Instruments
Categories: Latches
Quality Control: Learn More
Texas Instruments SN74ABT841ADWG4 is a single, transparent D-type latch from the 74ABT series. This 10:10 circuit features tri-state outputs capable of sourcing 32mA and sinking 64mA. With a propagation delay of 4.1ns, it is suitable for high-speed digital applications. The device is configured for 10 individual latch channels. It operates from a 4.5V to 5.5V supply and is packaged in a 24-SOIC (0.295", 7.50mm width) for surface mounting. The operating temperature range is -40°C to 85°C. This component is commonly utilized in telecommunications, industrial automation, and consumer electronics.
Additional Information
Series: 74ABTRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 24-SOIC (0.295"", 7.50mm Width) |
| Output Type | Tri-State |
| Mounting Type | Surface Mount |
| Circuit | 10:10 |
| Logic Type | D-Type Transparent Latch |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 4.5V ~ 5.5V |
| Independent Circuits | 1 |
| Current - Output High, Low | 32mA, 64mA |
| Delay Time - Propagation | 4.1ns |
| Supplier Device Package | 24-SOIC |
