SN74HC00N
IC GATE NAND 4CH 2-INP 14DIPManufacturer: Texas Instruments
Categories: Gates and Inverters
Quality Control: Learn More
NAND Gate IC 4 Channel 14-PDIP
Additional Information
Series: 74HCRoHS Status: ROHS3 CompliantManufacturer Lead Time: 6 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tube |
| Package / Case | 14-DIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Logic Type | NAND Gate |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 2V ~ 6V |
| Current - Output High, Low | 5.2mA, 5.2mA |
| Number of Inputs | 2 |
| Supplier Device Package | 14-PDIP |
| Input Logic Level - High | 1.5V ~ 4.2V |
| Input Logic Level - Low | 0.5V ~ 1.8V |
| Max Propagation Delay @ V, Max CL | 15ns @ 6V, 50pF |
| Number of Circuits | 4 |
| Current - Quiescent (Max) | 2 µA |
