SN74AUP1G08DBVT
IC GATE AND 1CH 2-INP SOT23-5Manufacturer: Texas Instruments
Categories: Gates and Inverters
Quality Control: Learn More
AND Gate IC 1 Channel SOT-23-5
Additional Information
Series: 74AUPRoHS Status: ROHS3 CompliantManufacturer Lead Time: 12 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-74A, SOT-753 |
| Mounting Type | Surface Mount |
| Logic Type | AND Gate |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 0.8V ~ 3.6V |
| Current - Output High, Low | 4mA, 4mA |
| Number of Inputs | 2 |
| Supplier Device Package | SOT-23-5 |
| Input Logic Level - High | 1.6V ~ 2V |
| Input Logic Level - Low | 0.7V ~ 0.9V |
| Max Propagation Delay @ V, Max CL | 6.2ns @ 3.3V, 30pF |
| Number of Circuits | 1 |
| Current - Quiescent (Max) | 500 nA |
Request a Quote
