SNJ54AC74FK
DUAL POSITIVE-EDGE-TRIGGERED D-TManufacturer: Texas Instruments
Categories: Flip Flops
Quality Control: Learn More
Flip Flop 2 Element D-Type 1 Bit Positive Edge 20-CLCC
Additional Information
Series: 54ACRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 20-CLCC |
| Output Type | Complementary |
| Mounting Type | Surface Mount |
| Number of Elements | 2 |
| Function | Set(Preset) and Reset |
| Type | D-Type |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Voltage - Supply | 2V ~ 6V |
| Current - Quiescent (Iq) | 2 µA |
| Current - Output High, Low | 24mA, 24mA |
| Trigger Type | Positive Edge |
| Clock Frequency | 160 MHz |
| Input Capacitance | 3 pF |
| Supplier Device Package | 20-LCCC (8.89x8.89) |
| Max Propagation Delay @ V, Max CL | 10ns @ 5V, 50pF |
| Number of Bits per Element | 1 |
Request a Quote
