SN74LVC1G80YZAR
IC FF D-TYPE SNGL 1BIT 5DSBGAManufacturer: Texas Instruments
Categories: Flip Flops
Quality Control: Learn More
Texas Instruments SN74LVC1G80YZAR is a single-bit, positive-edge triggered D-type flip-flop from the 74LVC series. This device features an inverted output and operates from 1.65V to 5.5V. It boasts a maximum propagation delay of 4.5ns at 5V and 50pF, with a clock frequency up to 160 MHz. The component offers robust output drive capabilities of 32mA high and 32mA low, and a quiescent current of just 10 µA. Designed for surface mounting, it is supplied in a compact 5-DSBGA (1.4x0.9) package, presented on a Tape & Reel (TR). This D-type flip-flop finds application in various digital systems, including computing, industrial automation, and consumer electronics.
Additional Information
Series: 74LVCRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 5-XFBGA, DSBGA |
| Output Type | Inverted |
| Mounting Type | Surface Mount |
| Number of Elements | 1 |
| Function | Standard |
| Type | D-Type |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply | 1.65V ~ 5.5V |
| Current - Quiescent (Iq) | 10 µA |
| Current - Output High, Low | 32mA, 32mA |
| Trigger Type | Positive Edge |
| Clock Frequency | 160 MHz |
| Input Capacitance | 3.5 pF |
| Supplier Device Package | 5-DSBGA (1.4x0.9) |
| Max Propagation Delay @ V, Max CL | 4.5ns @ 5V, 50pF |
| Number of Bits per Element | 1 |
