SN74AHC74PWR-P
IC FF D-TYPE DUAL 1BIT 14TSSOPManufacturer: Texas Instruments
Categories: Flip Flops
Quality Control: Learn More
Texas Instruments SN74AHC74PWR-P is a dual, independent D-type flip-flop from the 74AHC series. Each element features preset and clear asynchronous inputs, a positive edge-triggered clock input, and complementary Q and Q outputs. This device operates with a supply voltage range of 2V to 5.5V and a maximum clock frequency of 115 MHz. Typical propagation delay at 5V and 50pF load is 9.3ns. Output drive capability is 8mA for both high and low states, with a quiescent current of 2 µA. The surface mount component is housed in a 14-TSSOP package with a 4.40mm width. This device finds application in digital logic, control systems, and data buffering within the industrial and consumer electronics sectors.
Additional Information
Series: 74AHCRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 14-TSSOP (0.173"", 4.40mm Width) |
| Output Type | Complementary |
| Mounting Type | Surface Mount |
| Number of Elements | 2 |
| Function | Set(Preset) and Reset |
| Type | D-Type |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Voltage - Supply | 2V ~ 5.5V |
| Current - Quiescent (Iq) | 2 µA |
| Current - Output High, Low | 8mA, 8mA |
| Trigger Type | Positive Edge |
| Clock Frequency | 115 MHz |
| Input Capacitance | 2 pF |
| Supplier Device Package | 14-TSSOP |
| Max Propagation Delay @ V, Max CL | 9.3ns @ 5V, 50pF |
| Number of Bits per Element | 1 |
