CD22M3494EZR5276
IC CROSSPOINT SW 1 X 16:8 40DIPManufacturer: Renesas Electronics Corporation
Categories: Signal Switches, Multiplexers, Decoders
Quality Control: Learn More
Renesas Electronics Corporation's CD22M3494EZR5276 is a high-performance crosspoint switch designed for complex signal routing applications. This through-hole component, housed in a 40-PDIP package, features a 1 x 16:8 circuit configuration, enabling flexible signal distribution. Operating across a voltage range of 4V to 15V, it supports both analog and digital supply sources, making it suitable for diverse system architectures. The CD22M3494EZR5276 is engineered for reliability with an operating temperature range of -40°C to 85°C. Its robust design and extensive switching capabilities find application in telecommunications, broadcast equipment, and data acquisition systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 40-DIP (0.600"", 15.24mm) |
| Mounting Type | Through Hole |
| Circuit | 1 x 16:8 |
| Type | Crosspoint Switch |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply | 4V ~ 15V |
| Current - Output High, Low | - |
| Voltage Supply Source | Analog and Digital |
| Supplier Device Package | 40-PDIP |
