IDT7204L20SO8
IC FIFO ASYNC 4KX9 20NS 28SOICManufacturer: Renesas Electronics Corporation
Categories: FIFOs Memory
Quality Control: Learn More
Renesas Electronics Corporation IDT7204L20SO8 is a 4K x 9 asynchronous FIFO memory device from the 7200 series. This uni-directional FIFO offers a 20ns access time and supports a data rate of 33.3MHz. The device features retries and expansion capabilities for both depth and width, with a total memory size of 36K bits. It operates from a 4.5V to 5.5V supply voltage, with a maximum current draw of 120mA. The IDT7204L20SO8 is provided in a 28-SOIC surface mount package, supplied on tape and reel. This component is commonly utilized in data buffering and synchronization applications across various industries, including telecommunications and industrial automation.
Additional Information
Series: 7200RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 28-SOIC (0.345"", 8.77mm Width) |
| Mounting Type | Surface Mount |
| Function | Asynchronous |
| Memory Size | 36K (4K x 9) |
| Operating Temperature | 0°C ~ 70°C |
| Data Rate | 33.3MHz |
| Access Time | 20ns |
| Current - Supply (Max) | 120mA |
| Supplier Device Package | 28-SOIC |
| Bus Directional | Uni-Directional |
| Expansion Type | Depth, Width |
| Programmable Flags Support | No |
| Retransmit Capability | Yes |
| FWFT Support | No |
| Voltage - Supply | 4.5 V ~ 5.5 V |
| Programmable | Not Verified |
