72V36100L6BCY
IC FIFO ASYNC/SYNC 64KX36 4NSManufacturer: Renesas Electronics Corporation
Categories: FIFOs Memory
Quality Control: Learn More
Renesas Electronics Corporation's 72V36100L6BCY is a high-performance Asynchronous, Synchronous FIFO memory component from the 72V series. This uni-directional device offers a generous 2.25M memory size, configured as 64K words by 36 bits, with a rapid 4ns access time. Operating at a data rate of 166MHz, it supports both depth and width expansion for flexible system integration. The 72V36100L6BCY features First-Word-Fall-Through (FWFT) support and Programmable Flags, enhancing its utility in demanding applications. Retransmit capability further adds to its robust functionality. This component is suitable for high-speed data buffering and buffering applications across various industries including telecommunications, networking, and digital signal processing, operating within a voltage range of 3.15V to 3.45V and drawing a maximum of 40mA. The device is supplied in Tray packaging.
Additional Information
Series: 72VRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | - |
| Mounting Type | - |
| Function | Asynchronous, Synchronous |
| Memory Size | 2.25M (64K x 36) |
| Operating Temperature | 0°C ~ 70°C |
| Data Rate | 166MHz |
| Access Time | 4ns |
| Current - Supply (Max) | 40mA |
| Supplier Device Package | - |
| Bus Directional | Uni-Directional |
| Expansion Type | Depth, Width |
| Programmable Flags Support | Yes |
| Retransmit Capability | Yes |
| FWFT Support | Yes |
| Voltage - Supply | 3.15 V ~ 3.45 V |
| Programmable | Not Verified |
