72V205L10PFG8
IC FIFO SYNC 256X18 6.5NS 64QFPManufacturer: Renesas Electronics Corporation
Categories: FIFOs Memory
Quality Control: Learn More
The Renesas Electronics Corporation 72V series synchronous FIFO, part number 72V205L10PFG8, offers a 4.5K (256 x 18) memory configuration with a uni-directional data flow. This device operates at a 100MHz data rate and features a fast 6.5ns access time. Designed for surface mount applications, it is supplied in a 64-TQFP (14x14) package, delivered on tape and reel. The 72V205L10PFG8 supports First Word Fall Through (FWFT) and programmable flags, with expansion capabilities in both depth and width. This component is suitable for applications requiring high-speed data buffering and synchronization, commonly found in telecommunications and networking infrastructure. The operating voltage range is 3V to 3.6V, with a maximum supply current of 30mA.
Additional Information
Series: 72VRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 64-LQFP |
| Mounting Type | Surface Mount |
| Function | Synchronous |
| Memory Size | 4.5K (256 x 18) |
| Operating Temperature | 0°C ~ 70°C |
| Data Rate | 100MHz |
| Access Time | 6.5ns |
| Current - Supply (Max) | 30mA |
| Supplier Device Package | 64-TQFP (14x14) |
| Bus Directional | Uni-Directional |
| Expansion Type | Depth, Width |
| Programmable Flags Support | Yes |
| Retransmit Capability | No |
| FWFT Support | Yes |
| Voltage - Supply | 3 V ~ 3.6 V |
| Programmable | Not Verified |
