72T7285L4-4BBG
IC FIFO ASYNC/SYNC 16KX72 324BGAManufacturer: Renesas Electronics Corporation
Categories: FIFOs Memory
Quality Control: Learn More
The Renesas Electronics Corporation 72T7285L4-4BBG is a high-performance, 1.125M (16K x 72) Asynchronous and Synchronous FIFO. This uni-directional memory device supports data rates up to 225MHz with access times as low as 3.4ns. Featuring FWFT (First Word Fall-Through) support and retransmit capability, it operates from a 2.375V to 2.625V supply with a maximum current draw of 130mA. The 72T series component is housed in a 324-PBGA (19x19) package, suitable for surface mounting. It finds application in high-speed data buffering and buffering between disparate clock domains in telecommunications, networking, and industrial automation systems.
Additional Information
Series: 72TRoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 324-BGA |
| Mounting Type | Surface Mount |
| Function | Asynchronous, Synchronous |
| Memory Size | 1.125M (16K x 72) |
| Operating Temperature | 0°C ~ 70°C |
| Data Rate | 100MHz, 225MHz |
| Access Time | 8ns, 3.4ns |
| Current - Supply (Max) | 130mA |
| Supplier Device Package | 324-PBGA (19x19) |
| Bus Directional | Uni-Directional |
| Expansion Type | Depth, Width |
| Programmable Flags Support | Yes |
| Retransmit Capability | Yes |
| FWFT Support | Yes |
| Voltage - Supply | 2.375 V ~ 2.625 V |
| Programmable | Not Verified |
