QS54FCT244ATDB
IC BUFFER NON-INVERT 5VManufacturer: Quality Semiconductor
Categories: Buffers, Drivers, Receivers, Transceivers
Quality Control: Learn More
Quality Semiconductor QS54FCT244ATDB is a high-speed, non-inverting buffer/line driver designed for 5V operation. This electronic component features two 4-bit elements, providing a total of eight buffer channels. Each channel offers a 3-state output, allowing for bus contention management in complex digital systems. With a robust drive capability of 48mA high and 12mA low, it is well-suited for applications requiring significant output current. The QS54FCT244ATDB is packaged for through-hole mounting and operates across an industrial temperature range of -55°C to 125°C. Its performance characteristics make it a valuable component in telecommunications, industrial automation, and computing systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | - |
| Output Type | 3-State |
| Mounting Type | Through Hole |
| Number of Elements | 2 |
| Logic Type | Buffer, Non-Inverting, Line Driver |
| Operating Temperature | -55°C ~ 125°C |
| Voltage - Supply | 5V |
| Input Type | - |
| Number of Bits per Element | 4 |
| Current - Output High, Low | 48mA, 12mA |
| Supplier Device Package | - |
