NLSX4014MUTAG
IC TRANSLTR BIDIRECTIONAL 12UQFNManufacturer: onsemi
Categories: Translators, Level Shifters
Quality Control: Learn More
The onsemi NLSX4014MUTAG is a single-circuit, 4-channel bidirectional voltage level translator. This device offers automatic direction sensing, simplifying design by detecting signal transitions without requiring a direction control pin. Operating with VCCA ranging from 0.9V to 4.1V and VCCB from 1.3V to 4.5V, it supports a maximum data rate of 140Mbps. The output type is Tri-State, Non-Inverted. Packaged in a compact 12-UQFN (1.7x2) format, this component is suitable for surface mounting and is supplied on tape and reel. It finds application in portable electronics, automotive systems, and industrial automation where voltage level compatibility between different logic domains is essential.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Auto-Direction Sensing |
| Packaging | Tape & Reel (TR) |
| Package / Case | 12-UFQFN |
| Output Type | Tri-State, Non-Inverted |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Data Rate | 140Mbps |
| Supplier Device Package | 12-UQFN (1.7x2) |
| Channel Type | Bidirectional |
| Output Signal | - |
| Translator Type | Voltage Level |
| Channels per Circuit | 4 |
| Voltage - VCCA | 0.9 V ~ 4.1 V |
| Voltage - VCCB | 1.3 V ~ 4.5 V |
| Input Signal | - |
| Number of Circuits | 1 |
