DM74155N
IC DECODER/DEMULTIPLEX 16DIPManufacturer: onsemi
Categories: Signal Switches, Multiplexers, Decoders
Quality Control: Learn More
The onsemi DM74155N is a dual 1-of-4 decoder/demultiplexer packaged in a 16-PDIP. This device features two independent 1-of-4 decoding/demultiplexing sections, each with a common select input and an enable input. The DM74155N is suitable for applications requiring address decoding, data distribution, and control signal generation in digital systems. Its through-hole mounting makes it a versatile component for breadboarding and through-hole PCB assembly. This component finds application in various electronic systems including telecommunications, industrial control, and consumer electronics.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BagDownload Free CAD Model:
Technical Details:
| Packaging | Bag |
| Package / Case | 16-DIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Circuit | - |
| Type | Decoder/Demultiplexer |
| Operating Temperature | - |
| Voltage - Supply | - |
| Current - Output High, Low | - |
| Voltage Supply Source | - |
| Supplier Device Package | 16-PDIP |
Request a Quote
