74ACQ373PC
IC D-TYPE TRANSP SGL 8:8 20DIPManufacturer: onsemi
Categories: Latches
Quality Control: Learn More
The onsemi 74ACQ373PC is an 8:8 D-Type Transparent Latch featuring tri-state outputs. This single, independent octal latch operates across a 2V to 6V supply voltage range, with a typical propagation delay of 5.5ns. It offers robust current drive capabilities of 24mA for both high and low outputs. The 74ACQ373PC is housed in a 20-pin Dual In-line Package (PDIP) with a 0.300" lead pitch, suitable for through-hole mounting. This component is widely utilized in telecommunications and industrial automation applications requiring high-speed data buffering and storage. The device operates within an ambient temperature range of -40°C to 85°C and is supplied in tubes.
Additional Information
Series: 74ACQRoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 20-DIP (0.300"", 7.62mm) |
| Output Type | Tri-State |
| Mounting Type | Through Hole |
| Circuit | 8:8 |
| Logic Type | D-Type Transparent Latch |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 2V ~ 6V |
| Independent Circuits | 1 |
| Current - Output High, Low | 24mA, 24mA |
| Delay Time - Propagation | 5.5ns |
| Supplier Device Package | 20-PDIP |
