NC7WP08K8X
IC GATE AND 2CH 2-INP US8Manufacturer: onsemi
Categories: Gates and Inverters
Quality Control: Learn More
The onsemi 7WP series NC7WP08K8X is a dual 2-input AND gate, supplied in an 8-VFSOP (US8) package. This CMOS logic device operates across a broad voltage range of 0.9V to 3.6V, with quiescent current typically at 900 nA. Propagation delay is rated at 9.2ns at 3.3V with a 30pF load. Input logic levels are specified with a low threshold of 0.7V to 0.9V and a high threshold of 1.6V to 2.1V. Output drive capability is 2.6mA for both high and low states. This component is suitable for applications in consumer electronics and industrial automation.
Additional Information
Series: 7WPRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-VFSOP (0.091"", 2.30mm Width) |
| Mounting Type | Surface Mount |
| Logic Type | AND Gate |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 0.9V ~ 3.6V |
| Current - Output High, Low | 2.6mA, 2.6mA |
| Number of Inputs | 2 |
| Supplier Device Package | US8 |
| Input Logic Level - High | 1.6V ~ 2.1V |
| Input Logic Level - Low | 0.7V ~ 0.9V |
| Max Propagation Delay @ V, Max CL | 9.2ns @ 3.3V, 30pF |
| Number of Circuits | 2 |
| Current - Quiescent (Max) | 900 nA |
