MM74C76N
IC FF JK TYPE DUAL 1BIT 16DIPManufacturer: onsemi
Categories: Flip Flops
Quality Control: Learn More
The onsemi MM74C76N is a dual JK-type flip-flop from the 74C series, supplied in a 16-PDIP package. This component features negative edge triggering and includes direct set and reset capabilities. Each of the two JK flip-flop elements is designed for single-bit operation. The device operates with a supply voltage range of 3V to 15V and supports clock frequencies up to 11 MHz. Output current capabilities are 8mA for both high and low states, with complementary outputs. Input capacitance is rated at 5 pF. This component is suitable for various industrial applications, including control systems and digital logic circuits. It is manufactured by onsemi.
Additional Information
Series: 74CRoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 16-DIP (0.300"", 7.62mm) |
| Output Type | Complementary |
| Mounting Type | Through Hole |
| Number of Elements | 2 |
| Function | Set(Preset) and Reset |
| Type | JK Type |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Voltage - Supply | 3V ~ 15V |
| Current - Output High, Low | 8mA, 8mA |
| Trigger Type | Negative Edge |
| Clock Frequency | 11 MHz |
| Input Capacitance | 5 pF |
| Supplier Device Package | 16-PDIP |
| Number of Bits per Element | 1 |
