SN74LS126AD
IC BUFF NON-INVERT 5.25V 14SOICManufacturer: onsemi
Categories: Buffers, Drivers, Receivers, Transceivers
Quality Control: Learn More
Buffer, Non-Inverting 4 Element 1 Bit per Element 3-State Output 14-SOIC
Additional Information
Series: 74LSRoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 14-SOIC (0.154"", 3.90mm Width) |
| Output Type | 3-State |
| Mounting Type | Surface Mount |
| Number of Elements | 4 |
| Logic Type | Buffer, Non-Inverting |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Voltage - Supply | 4.75V ~ 5.25V |
| Input Type | - |
| Number of Bits per Element | 1 |
| Current - Output High, Low | 2.6mA, 24mA |
| Supplier Device Package | 14-SOIC |
