DM74LS126AN
IC BUF NON-INVERT 5.25V 14DIPManufacturer: onsemi
Categories: Buffers, Drivers, Receivers, Transceivers
Quality Control: Learn More
onsemi DM74LS126AN is a TTL buffer featuring four independent non-inverting buffer elements. Each element provides a single bit of buffering, with a typical output current capability of 2.6mA high and 24mA low. This component operates within a supply voltage range of 4.75V to 5.25V. Designed for through-hole mounting, it is supplied in a 14-MDIP package. The DM74LS126AN is suitable for applications in industrial control, consumer electronics, and communication systems. Its operating temperature range is 0°C to 70°C.
Additional Information
Series: 74LSRoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 14-DIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Number of Elements | 4 |
| Logic Type | Buffer, Non-Inverting |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Voltage - Supply | 4.75V ~ 5.25V |
| Number of Bits per Element | 1 |
| Current - Output High, Low | 2.6mA, 24mA |
| Supplier Device Package | 14-MDIP |
