74LCXH245MSAX
IC TXRX NON-INVERT 3.6V 20SSOPManufacturer: onsemi
Categories: Buffers, Drivers, Receivers, Transceivers
Quality Control: Learn More
The onsemi 74LCXH245MSAX is a high-performance, low-voltage, CMOS octal transceiver with 3-state outputs. This non-inverting, 8-bit transceiver features a wide operating voltage range from 2V to 3.6V, making it suitable for a variety of applications. With 24mA drive capability for both high and low outputs, it ensures robust signal integrity. The 74LCXH series component is supplied in a 20-SSOP package for surface mounting, optimized for high-density designs. Its 3-state output capability allows for efficient bus sharing. This device is commonly utilized in industrial automation, consumer electronics, and telecommunications systems where reliable data transmission and low power consumption are critical. The 74LCXH245MSAX is delivered on tape and reel for automated assembly processes.
Additional Information
Series: 74LCXHRoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 20-SSOP (0.209"", 5.30mm Width) |
| Output Type | 3-State |
| Mounting Type | Surface Mount |
| Number of Elements | 1 |
| Logic Type | Transceiver, Non-Inverting |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply | 2V ~ 3.6V |
| Input Type | - |
| Number of Bits per Element | 8 |
| Current - Output High, Low | 24mA, 24mA |
| Supplier Device Package | 20-SSOP |
