74AXP1T57DC-Q100H
74AXP1T57DC-Q100/SOT765/VSSOP8Manufacturer: Nexperia USA Inc.
Categories: Gates and Inverters - Multi-Function, Configurable
Quality Control: Learn More
Nexperia USA Inc.'s 74AXP1T57DC-Q100H is a configurable multiple-function logic gate from the 74AXP series. This automotive-qualified AEC-Q100 device features one circuit with three inputs and a single-ended output. It operates over a wide supply voltage range of 1.2V to 5.5V and a temperature range of -40°C to 125°C. The 8-VSSOP package provides a compact surface-mount solution. Key features include Schmitt trigger inputs and a configurable logic architecture, making it suitable for complex digital designs in automotive applications, including infotainment and advanced driver-assistance systems. The device is supplied in Tape & Reel packaging.
Additional Information
Series: 74AXPRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-VFSOP (0.091"", 2.30mm Width) |
| Output Type | Single-Ended |
| Mounting Type | Surface Mount |
| Logic Type | Configurable Multiple Function |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Supply | 1.2V ~ 5.5V |
| Current - Output High, Low | - |
| Number of Inputs | 3 |
| Schmitt Trigger Input | Yes |
| Supplier Device Package | 8-VSSOP |
| Grade | Automotive |
| Number of Circuits | 1 |
| Qualification | AEC-Q100 |
