HV5623K7-G
IC 32BIT SRL PARALLEL 44WQFNManufacturer: Microchip Technology
Categories: Shift Registers
Quality Control: Learn More
Microchip Technology's HV5623K7-G is a 32-bit serial-to-parallel shift register. This high-voltage device features open-drain outputs and operates from a 4.5V to 5.5V supply. The component is housed in a 44-pin, 7x7mm WQFN package with an exposed pad, facilitating efficient surface mounting. Designed for applications requiring robust high-voltage switching and control, its architecture is suitable for use in industrial automation, display driving, and power management systems. The single 32-bit element configuration provides a compact solution for serial data distribution and parallel output needs. Operating within a temperature range of -40°C to 85°C, the HV5623K7-G ensures reliable performance in demanding environments.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 35 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 44-WFQFN Exposed Pad |
| Output Type | Open Drain |
| Mounting Type | Surface Mount |
| Number of Elements | 1 |
| Function | Serial to Parallel |
| Logic Type | Shift Register |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 4.5V ~ 5.5V |
| Supplier Device Package | 44-QFN (7x7) |
| Number of Bits per Element | 32 |
