CY7C4225V-15ASXCT
IC FIFO SYNC 1KX18 11NS 64TQFPManufacturer: Infineon Technologies
Categories: FIFOs Memory
Quality Control: Learn More
Infineon Technologies CY7C4225V-15ASXCT is a synchronous FIFO memory component from the CY7C series. This uni-directional, 1K x 18 configuration offers an 18K bit memory organization with a maximum clock frequency of 66.7MHz and an access time of 11ns. Designed for surface mount applications, it is supplied in a 64-TQFP (14x14) package and delivered on tape and reel. The device supports programmable flags and retransmit capability, operating across a voltage range of 3V to 3.6V with a maximum supply current of 30mA. This component is utilized in applications requiring high-speed data buffering and synchronization, such as telecommunications infrastructure, industrial automation, and high-performance computing.
Additional Information
Series: CY7CRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 64-LQFP |
| Mounting Type | Surface Mount |
| Function | Synchronous |
| Memory Size | 18K (1K x 18) |
| Operating Temperature | 0°C ~ 70°C |
| Data Rate | 66.7MHz |
| Access Time | 11ns |
| Current - Supply (Max) | 30mA |
| Supplier Device Package | 64-TQFP (14x14) |
| Bus Directional | Uni-Directional |
| Expansion Type | Depth, Width |
| Programmable Flags Support | Yes |
| Retransmit Capability | Yes |
| FWFT Support | No |
| Voltage - Supply | 3 V ~ 3.6 V |
| Programmable | Not Verified |
