CD4027BD3
DUAL J-K FLIP-FLOPManufacturer: Harris Corporation
Categories: Flip Flops
Quality Control: Learn More
Flip Flop 2 Element JK Type 1 Bit Positive Edge 16-CDIP (0.300"", 7.62mm)
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 16-CDIP (0.300"", 7.62mm) |
| Output Type | Complementary |
| Mounting Type | Through Hole |
| Number of Elements | 2 |
| Function | Set(Preset) and Reset |
| Type | JK Type |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Voltage - Supply | 3V ~ 18V |
| Current - Quiescent (Iq) | 20 µA |
| Current - Output High, Low | 6.8mA, 6.8mA |
| Trigger Type | Positive Edge |
| Clock Frequency | 24 MHz |
| Input Capacitance | 5 pF |
| Supplier Device Package | 16-CDIP |
| Max Propagation Delay @ V, Max CL | 90ns @ 15V, 50pF |
| Number of Bits per Element | 1 |
