74VCXF162835MTX
BUS DRIVERManufacturer: Fairchild Semiconductor
Categories: Universal Bus Functions
Quality Control: Learn More
Fairchild Semiconductor's 74VCXF162835MTX is an 18-bit universal bus driver designed for high-performance applications. This CMOS device operates over a wide supply voltage range of 1.65V to 3.6V, featuring low-voltage translation capabilities. The 74VCX series logic offers excellent noise immunity and fast switching speeds. With a symmetrical drive strength of 12mA at both high and low output levels, it is well-suited for demanding bus interfacing. The device is supplied in a 56-TSSOP package, facilitating surface mounting for compact board designs. Its robust operating temperature range of -40°C to 85°C makes it suitable for various industrial and consumer electronics sectors.
Additional Information
Series: 74VCXRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 56-TFSOP (0.240"", 6.10mm Width) |
| Number of Circuits | 18-Bit |
| Mounting Type | Surface Mount |
| Logic Type | Universal Bus Driver |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 1.65V ~ 3.6V |
| Current - Output High, Low | 12mA, 12mA |
| Supplier Device Package | 56-TSSOP |
