PI3C3125LE
IC BUS SWITCH 1 X 1:1 14TSSOPManufacturer: Diodes Incorporated
Categories: Signal Switches, Multiplexers, Decoders
Quality Control: Learn More
The Diodes Incorporated PI3C3125LE is a high-performance analog switch designed for efficient signal routing. This single-pole, single-throw (SPST) bus switch features a 1 x 1:1 circuit configuration, enabling precise control over signal paths within complex systems. With four independent circuits, the PI3C3125LE offers flexibility for various signal management tasks.
Operating from a single supply voltage range of 2.3V to 3.6V, this component is suitable for a wide array of low-voltage applications. Its 14-TSSOP (0.173", 4.40mm Width) package facilitates efficient board space utilization, making it ideal for surface mount assembly. The PI3C3125LE is engineered for reliable operation across an industrial temperature range of -40°C to 85°C. This device finds application in sectors such as consumer electronics, industrial control, and data communications, where robust signal switching is paramount.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 14-TSSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Circuit | 1 x 1:1 |
| Type | Bus Switch |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 2.3V ~ 3.6V |
| Independent Circuits | 4 |
| Current - Output High, Low | - |
| Voltage Supply Source | Single Supply |
| Supplier Device Package | 14-TSSOP |
