HMC843LC4BTR-R5
IC GATE AND/NAND/OR/NOR 24QFNManufacturer: Analog Devices Inc.
Categories: Gates and Inverters - Multi-Function, Configurable
Quality Control: Learn More
Analog Devices Inc. HMC843LC4BTR-R5 is a configurable logic gate solution offering AND, NAND, NOR, and OR functionality. This single-circuit component features four inputs and is housed in a 24-CSMT (4x4) package, Mountable via Surface Mount. The device operates within a supply voltage range of -3.13V to -3.47V and is specified for operation between -40°C and 70°C. Its output types include both Differential and Single-Ended. This component is utilized in various applications across industrial and communications sectors. The HMC843LC4BTR-R5 is supplied on Tape & Reel (TR).
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 24-TFCQFN Exposed Pad |
| Output Type | Differential, Single-Ended |
| Mounting Type | Surface Mount |
| Logic Type | AND/NAND/NOR/OR GATE |
| Operating Temperature | -40°C ~ 70°C |
| Voltage - Supply | -3.13V ~ -3.47V |
| Current - Output High, Low | - |
| Number of Inputs | 4 |
| Schmitt Trigger Input | No |
| Supplier Device Package | 24-CSMT (4x4) |
| Number of Circuits | 1 |
