AM25S09/BEA
AM25S09 - MUX, QUAD 2 LINE INPUTManufacturer: Advanced Micro Devices
Categories: Flip Flops
Quality Control: Learn More
Flip Flop 1 Element D-Type 4 Bit Positive Edge 16-CDIP (0.300"", 7.62mm)
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 16-CDIP (0.300"", 7.62mm) |
| Output Type | Non-Inverted |
| Mounting Type | Through Hole |
| Number of Elements | 1 |
| Function | Reset |
| Type | D-Type |
| Operating Temperature | -55°C ~ 125°C |
| Voltage - Supply | 4.5V ~ 5.5V |
| Current - Quiescent (Iq) | 120 mA |
| Current - Output High, Low | 20mA, 1mA |
| Trigger Type | Positive Edge |
| Supplier Device Package | 16-CDIP |
| Max Propagation Delay @ V, Max CL | 17ns @ 5V, 15pF |
| Number of Bits per Element | 4 |
Request a Quote
