Z88C0020PSG
IC MCU 8BIT ROMLESS 40DIPManufacturer: Zilog
Categories: Microcontrollers
Quality Control: Learn More
The Zilog Z8® Super8 microcontroller, part number Z88C0020PSG, is an 8-bit, ROMless device operating at up to 20MHz. This component features a Z8 core and offers 128K x 8 RAM. Connectivity includes a UART/USART interface. Peripherals such as DMA are integrated. With 32 I/O pins, this microcontroller is housed in a 40-DIP (0.620", 15.75mm) through-hole package. The operating voltage range is 4.75V to 5.25V, with an operating temperature of 0°C to 70°C (TA). This device is commonly utilized in industrial automation and consumer electronics applications.
Additional Information
Series: Z8® Super8RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 40-DIP (0.620"", 15.75mm) |
| Mounting Type | Through Hole |
| Speed | 20MHz |
| Program Memory Size | - |
| RAM Size | 128K x 8 |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | ROMless |
| EEPROM Size | - |
| Core Processor | Z8 |
| Data Converters | - |
| Core Size | 8-Bit |
| Voltage - Supply (Vcc/Vdd) | 4.75V ~ 5.25V |
| Connectivity | UART/USART |
| Peripherals | DMA |
| Number of I/O | 32 |
| Programmable | Not Verified |
