Z8FS040BSB20EG
IC MCU 4KB FLASH 8SOICManufacturer: Zilog
Categories: Application Specific Microcontrollers
Quality Control: Learn More
Zilog ZMOTION® Z8FS040BSB20EG microcontroller, featuring a 4kB FLASH program memory and 256 x 8 bytes of RAM. This eZ8® core processor offers a 2.7V to 3.6V operating voltage range and operates efficiently across a -40°C to 105°C temperature spectrum. The device provides 5 I/O lines and a UART/USART interface, housed in an 8-SOIC (0.154", 3.90mm Width) package suitable for surface mounting. This component is commonly utilized in infrared motion detection applications, leveraging its capabilities within the Z8 Encore! XP® controller series.
Additional Information
Series: ZMOTION®RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Interface | UART/USART |
| RAM Size | 256 x 8 |
| Operating Temperature | -40°C ~ 105°C |
| Voltage - Supply | 2.7V ~ 3.6V |
| Controller Series | Z8 Encore! XP® |
| Program Memory Type | FLASH (4kB) |
| Applications | Infrared Motion Detection |
| Core Processor | eZ8® |
| Supplier Device Package | 8-SOIC |
| Number of I/O | 5 |
| Programmable | Verified |
