1616160000
TERM BLOCK HDR 4POS VERT 3.5MMManufacturer: Weidmüller
Categories: Headers, Plugs and Sockets
Quality Control: Learn More
4 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.138"" (3.50mm) Vertical Through Hole
Additional Information
Series: Omnimate SLRoHS Status: Request inventory verificationManufacturer Lead Time: 22 week(s)Product Status: ActivePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | Mating and Mounting Flange |
| Packaging | Bulk |
| Color | Black |
| Mounting Type | Through Hole |
| Number of Positions | 4 |
| Pitch | 0.138"" (3.50mm) |
| Type | Header, Male Pins, Shrouded (4 Side) |
| Operating Temperature | -20°C ~ 100°C |
| Termination Style | Solder |
| Current - IEC | 12A |
| Number of Levels | 1 |
| Wire Gauge or Range - AWG | - |
| Wire Gauge or Range - mm² | - |
| Positions Per Level | 4 |
| Header Orientation | Vertical |
| Plug Wire Entry | - |
| Contact Mating Finish | Tin |
| Current - UL | 10 A |
| Voltage - IEC | 125 V |
| Voltage - UL | 300 V |
