BYV60W-600PT2Q
DIODE GEN PURP 600V 60A TO247-2Manufacturer: WeEn Semiconductors
Categories: Single Diodes
Quality Control: Learn More
Diode 600 V 60A Through Hole TO-247-2
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 8 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-247-2 |
| Mounting Type | Through Hole |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 79 ns |
| Technology | Standard |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 60A |
| Supplier Device Package | TO-247-2 |
| Operating Temperature - Junction | 175°C |
| Voltage - DC Reverse (Vr) (Max) | 600 V |
| Voltage - Forward (Vf) (Max) @ If | 1.7 V @ 60 A |
| Current - Reverse Leakage @ Vr | 10 µA @ 600 V |
