LTH5MM1152V
LED GRN/RED DIFFUSED T-1 3/4 T/HManufacturer: Visual Communications Company - VCC
Categories: LED Indication - Discrete
Quality Control: Learn More
Green, Red 568nm Green, 617nm Red LED Indication - Discrete 2V Green, 2.2V Red Radial - 3 Leads
Additional Information
Series: LTH5MM115RoHS Status: ROHS3 CompliantManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial - 3 Leads |
| Color | Green, Red |
| Size / Dimension | - |
| Mounting Type | Through Hole |
| Millicandela Rating | 60mcd Green, 60mcd Red |
| Configuration | Common Cathode |
| Voltage - Forward (Vf) (Typ) | 2V Green, 2.2V Red |
| Lens Color | White |
| Current - Test | 20mA Green, 20mA Red |
| Viewing Angle | 30° |
| Height (Max) | 11.35mm |
| Wavelength - Peak | 565nm Green, 627nm Red |
| Wavelength - Dominant | 568nm Green, 617nm Red |
| Supplier Device Package | T-1 3/4 (5mm) |
| Lens Transparency | Diffused |
| Lens Style | Round with Domed Top |
| Lens Size | 5mm, T-1 3/4 |
