CMD95-21VGC/TR9
LED GREEN CLEAR YOKE LEAD SMDManufacturer: Visual Communications Company - VCC
Categories: LED Indication - Discrete
Quality Control: Learn More
Visual Communications Company (VCC) CMD95-21VGC-TR9 is a green, clear lens, round LED with a domed top, designed for surface mount applications. This discrete component features a 2.1V forward voltage (Vf) and a luminous intensity of 19.5 mcd at its dominant wavelength of 570nm. The LED is housed in a 2-SMD package with a yoke bend lead configuration, measuring 2.20mm in length and 2.10mm in width, with a maximum height of 2.82mm and a lens diameter of 1.70mm. The viewing angle is 25°. Supplied on a tape and reel (TR), this component is suitable for indication in various industrial and consumer electronics applications.
Additional Information
Series: -RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 2-SMD, Yoke Bend |
| Color | Green |
| Size / Dimension | 2.20mm L x 2.10mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | 19.5mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 2.1V |
| Lens Color | - |
| Current - Test | - |
| Viewing Angle | 25° |
| Height (Max) | 2.82mm |
| Wavelength - Peak | 570nm |
| Wavelength - Dominant | - |
| Supplier Device Package | Yoke Lead |
| Lens Transparency | Clear |
| Lens Style | Round with Domed Top |
| Lens Size | 1.70mm Dia |
