4302T5-5V
LED GREEN DIFFUSED T/HManufacturer: Visual Communications Company - VCC
Categories: LED Indication - Discrete
Quality Control: Learn More
Visual Communications Company (VCC) 4302T5-5V is a green diffused LED designed for through-hole mounting with a 5V forward voltage. This discrete indicator features a 1.78mm diameter round, domed lens with a diffused finish, providing a 90° viewing angle. The typical forward current at 10mA results in a luminous intensity of 5mcd. The axial package dimensions are 2.03mm L x 2.21mm W with a maximum height of 2.92mm. This component is utilized in various industrial and consumer electronic applications requiring reliable visual feedback.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Axial |
| Color | Green |
| Size / Dimension | 2.03mm L x 2.21mm W |
| Mounting Type | Through Hole |
| Millicandela Rating | 5mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 5V |
| Lens Color | Green |
| Current - Test | 10mA |
| Viewing Angle | 90° |
| Height (Max) | 2.92mm |
| Wavelength - Peak | 565nm |
| Wavelength - Dominant | - |
| Supplier Device Package | - |
| Lens Transparency | Diffused |
| Lens Style | Round with Domed Top |
| Lens Size | 1.78mm Dia |
