4300T7LC
LED YELLOW DIFFUSED T/HManufacturer: Visual Communications Company - VCC
Categories: LED Indication - Discrete
Quality Control: Learn More
Visual Communications Company (VCC) 4300 series, part number 4300T7LC, is a diffused yellow LED with a through-hole mounting type. This discrete LED operates with a typical forward voltage of 1.9V at a test current of 2mA, producing a millicandela rating of 0.6mcd. The component features a round, domed top lens with a yellow diffused finish, measuring 1.78mm in diameter and a maximum height of 2.92mm. Its peak wavelength is 583nm, with a broad viewing angle of 90°. This component is suitable for indication applications across various industries, including industrial automation, consumer electronics, and automotive systems. The part is supplied in bulk packaging.
Additional Information
Series: 4300RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Axial |
| Color | Yellow |
| Size / Dimension | - |
| Mounting Type | Through Hole |
| Millicandela Rating | 0.6mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 1.9V |
| Lens Color | Yellow |
| Current - Test | 2mA |
| Viewing Angle | 90° |
| Height (Max) | 2.92mm |
| Wavelength - Peak | 583nm |
| Wavelength - Dominant | - |
| Supplier Device Package | - |
| Lens Transparency | Diffused |
| Lens Style | Round with Domed Top |
| Lens Size | 1.78mm Dia |
