125-RG
LED GREEN/RED DIFFUSED T-1 T/HManufacturer: Visual Communications Company - VCC
Categories: LED Indication - Discrete
Quality Control: Learn More
Visual Communications Company (VCC) 125-RG is a T-1 (3mm) diffused, through-hole LED with dual Green and Red illumination. This discrete component offers typical forward voltages of 2.6V for Green and 2.1V for Red, with a 20mA test current for both. The Green emitter provides a dominant wavelength of 565nm with a luminous intensity of 5mcd, while the Red emitter operates at 630nm with a similar 5mcd intensity. The diffused, domed-top lens style and a 72° viewing angle are characteristic of this radial package. This component is suitable for various indication applications across industries such as industrial automation, medical devices, and consumer electronics.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial |
| Color | Green, Red |
| Size / Dimension | 3.00mm Dia |
| Mounting Type | Through Hole |
| Millicandela Rating | 5mcd Green, 5mcd Red |
| Configuration | - |
| Voltage - Forward (Vf) (Typ) | 2.6V Green, 2.1V Red |
| Lens Color | - |
| Current - Test | 20mA Green, 20mA Red |
| Viewing Angle | 72° |
| Height (Max) | 5.90mm |
| Wavelength - Peak | 565nm Green, 630nm Red |
| Wavelength - Dominant | - |
| Supplier Device Package | T-1 (3mm) |
| Lens Transparency | Diffused |
| Lens Style | Round with Domed Top |
| Lens Size | 3mm, T-1 |
