LED CBI 3MM 2X2 RED RAManufacturer: Visual Communications Company - VCC
Categories: Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Quality Control: Learn More
The Visual Communications Company (VCC) 5684F1-1-1-1 is a 2x2 LED Circuit Board Indicator in the 5684F series. This component features four individual red LEDs, each with a 3mm (T-1) diameter, tinted, domed top lens. The right-angle, through-hole mounting facilitates efficient PCB assembly. Each LED operates at a forward voltage of 2.2V and a forward current of 10mA, delivering a typical millicandela rating of 10mcd. This component is commonly utilized in industrial automation, medical equipment, and consumer electronics for status indication and panel illumination. The bulk packaging is suitable for high-volume manufacturing.
Additional Information
Series: 5684FRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Current | 10mA |
| Color | Red (x 4) |
| Voltage Rating | 2.2V |
| Mounting Type | Through Hole, Right Angle |
| Millicandela Rating | 10mcd |
| Configuration | 2 High x 2 Wide |
| Viewing Angle | - |
| Lens Type | Tinted |
| Wavelength - Peak | 635nm |
| Lens Style | Round with Domed Top |
| Lens Size | 3mm, T-1 |
