MMBD7000-HE3_A-18
SWITCHING DIODE GENPURP SOT23Manufacturer: Vishay
Categories: Diode Arrays
Quality Control: Learn More
Diode Array 1 Pair Series Connection 100 V 350mA Surface Mount TO-236-3, SC-59, SOT-23-3
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 14 week(s)Product Status: ActivePackaging: Digi-Reel®Download Free CAD Model:
Technical Details:
| Packaging | Digi-Reel® |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 4 ns |
| Technology | Standard |
| Diode Configuration | 1 Pair Series Connection |
| Current - Average Rectified (Io) (per Diode) | 350mA |
| Supplier Device Package | SOT-23-3 |
| Operating Temperature - Junction | 150°C |
| Grade | Automotive |
| Voltage - DC Reverse (Vr) (Max) | 100 V |
| Voltage - Forward (Vf) (Max) @ If | 1.1 V @ 100 mA |
| Current - Reverse Leakage @ Vr | 3 µA @ 100 V |
| Qualification | AEC-Q101 |
