TR3V107K6R3C0200
CAP TANT 100UF 10% 6.3V 2917Manufacturer: Vishay Sprague
Categories: Tantalum Capacitors
Quality Control: Learn More
Vishay Sprague TANTAMOUNT™, TR3 series TR3V107K6R3C0200 is a molded tantalum capacitor with a capacitance of 100 µF and a voltage rating of 6.3 V. This component features a ±10% tolerance and a low equivalent series resistance (ESR) of 200 mOhm. Designed for surface mounting, it is packaged in the 2917 (7343 Metric) case, measuring 7.30mm x 4.30mm with a maximum seated height of 2.00mm. The operating temperature range is -55°C to 125°C. This general-purpose capacitor is suitable for applications in industrial, consumer electronics, and automotive sectors. The TR3V107K6R3C0200 is supplied on tape and reel.
Additional Information
Series: TANTAMOUNT™, TR3RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±10% |
| Features | General Purpose |
| Packaging | Tape & Reel (TR) |
| Package / Case | 2917 (7343 Metric) |
| Size / Dimension | 0.287"" L x 0.169"" W (7.30mm x 4.30mm) |
| Mounting Type | Surface Mount |
| Type | Molded |
| Operating Temperature | -55°C ~ 125°C |
| Lead Spacing | - |
| ESR (Equivalent Series Resistance) | 200mOhm |
| Lifetime @ Temp. | - |
| Manufacturer Size Code | V |
| Height - Seated (Max) | 0.079"" (2.00mm) |
| Failure Rate | - |
| Capacitance | 100 µF |
| Voltage - Rated | 6.3 V |
