80D223P016KE2DE3
CAP ALUM 22000UF 16V SNAP THManufacturer: Vishay Sprague
Categories: Aluminum Electrolytic Capacitors
Quality Control: Learn More
Vishay Sprague 80D series aluminum electrolytic capacitor, part number 80D223P016KE2DE3, offers a capacitance of 22000 µF with a 16 V rating. This radial, can-type component features snap-in terminals and a low equivalent series resistance of 35 mOhm at 120 Hz. Designed for through-hole mounting, it has a diameter of 1.181" (30.00mm), a height of 2.047" (52.00mm), and a lead spacing of 0.394" (10.00mm). The component is rated for 2000 hours of operation at 85°C. It is suitable for general-purpose applications and operates within a temperature range of -40°C to 85°C. This device supports a ripple current of 5.8 A at 120 Hz and 6.1 A at 40 kHz. Industries utilizing this component include industrial power supplies and consumer electronics.
Additional Information
Series: 80DRoHS Status: ROHS3 CompliantManufacturer Lead Time: 38 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Tolerance | -10%, +30% |
| Packaging | Bulk |
| Package / Case | Radial, Can - Snap-In |
| Size / Dimension | 1.181"" Dia (30.00mm) |
| Polarization | Polar |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 85°C |
| Applications | General Purpose |
| Lead Spacing | 0.394"" (10.00mm) |
| Ratings | - |
| ESR (Equivalent Series Resistance) | 35mOhm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Surface Mount Land Size | - |
| Height - Seated (Max) | 2.047"" (52.00mm) |
| Capacitance | 22000 µF |
| Voltage - Rated | 16 V |
| Ripple Current @ Low Frequency | 5.8 A @ 120 Hz |
| Ripple Current @ High Frequency | 6.1 A @ 40 kHz |
