152S502
POT 5K OHM 2W WIREWOUND LINEARManufacturer: Vishay Spectrol
Categories: Rotary Potentiometers, Rheostats
Quality Control: Learn More
5k Ohm 1 Gang Linear Servo Mount Potentiometer 1.0 Turns Wirewound 2W Solder Lug
Additional Information
Series: 152RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Resistance (Ohms) | 5K |
| Power (Watts) | 2W |
| Tolerance | ±3% |
| Features | - |
| Packaging | Box |
| Temperature Coefficient | - |
| Adjustment Type | User Defined |
| Mounting Type | Servo Mount |
| Termination Style | Solder Lug |
| Bushing Thread | - |
| Actuator Length | 0.500"" (12.70mm) |
| Actuator Type | Round |
| Built in Switch | None |
| Actuator Diameter | 0.125"" (3.18mm) |
| Resistive Material | Wirewound |
| Taper | Linear |
| Rotation | 360° |
| Number of Gangs | 1 |
| Number of Turns | 1.0 |
