DG542DY-T1-E3
IC SWITCH QUAD SPST 16SOICManufacturer: Vishay Siliconix
Categories: Special Purpose
Quality Control: Learn More
Vishay Siliconix DG542DY-T1-E3 is a quad single-pole, single-throw (SPST) analog switch. This 4-channel device offers a 500MHz -3dB bandwidth, making it suitable for demanding video applications. Key features include compatibility with RGB signals and a T-switch configuration for flexible signal routing. The DG542DY-T1-E3 operates with single or dual supply voltages ranging from ±3V to ±15V. It exhibits a maximum on-state resistance of 60 Ohms. The component is housed in a 16-SOIC package and is supplied on tape and reel. This Vishay Siliconix device is commonly utilized in video processing and display systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | RGB, T-Switch Configuration |
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Applications | Video |
| On-State Resistance (Max) | 60Ohm |
| -3db Bandwidth | 500MHz |
| Supplier Device Package | 16-SOIC |
| Voltage - Supply, Single (V+) | 3V ~ 15V |
| Voltage - Supply, Dual (V±) | ±3V ~ 15V |
| Switch Circuit | SPST |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Number of Channels | 4 |
