DG538ADN-E3
IC AMP/VIDEO/MUX LP 4/8CH 28PLCCManufacturer: Vishay Siliconix
Categories: Special Purpose
Quality Control: Learn More
Vishay Siliconix DG538ADN-E3 is a low-power, 2-channel analog multiplexer designed for high-bandwidth applications. Featuring a T-Switch configuration, this device offers a -3dB bandwidth of 500MHz, making it suitable for demanding video and ultrasound signal routing. Each channel supports a 4:1 multiplexing configuration, providing flexibility in signal selection. The DG538ADN-E3 exhibits a maximum on-state resistance of 90 Ohms, ensuring minimal signal attenuation. Its operating temperature range is -40°C to 85°C. The component is housed in a 28-PLCC package for surface mounting. This device is utilized in industries requiring precise signal management for medical imaging and broadcast video systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | T-Switch Configuration |
| Packaging | Bulk |
| Package / Case | 28-LCC (J-Lead) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Applications | Ultrasound, Video |
| On-State Resistance (Max) | 90Ohm |
| -3db Bandwidth | 500MHz |
| Supplier Device Package | 28-PLCC (11.51x11.51) |
| Voltage - Supply, Single (V+) | 10V ~ 21V |
| Voltage - Supply, Dual (V±) | - |
| Switch Circuit | - |
| Multiplexer/Demultiplexer Circuit | 4:1 |
| Number of Channels | 2 |
