IRF530S
MOSFET N-CH 100V 14A D2PAKManufacturer: Vishay Siliconix
Categories: Single FETs, MOSFETs
Quality Control: Learn More
The Vishay Siliconix IRF530S is a N-Channel Power MOSFET designed for demanding applications. This component features a Drain-to-Source Voltage (Vdss) of 100V and a continuous Drain Current (Id) of 14A at 25°C (Tc). With a low on-resistance (Rds On) of 160mOhm at 8.4A and 10V, it minimizes conduction losses. The device offers a maximum power dissipation of 88W (Tc) and is housed in a TO-263-3, D2PAK surface-mount package, facilitating efficient thermal management. Key parameters include a gate charge (Qg) of 26 nC at 10V and input capacitance (Ciss) of 670 pF at 25V. This MOSFET is suitable for use in power supply, motor control, and industrial automation sectors. It operates within an extended temperature range of -55°C to 175°C (TJ).
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 14A (Tc) |
| Rds On (Max) @ Id, Vgs | 160mOhm @ 8.4A, 10V |
| FET Feature | - |
| Power Dissipation (Max) | 3.7W (Ta), 88W (Tc) |
| Vgs(th) (Max) @ Id | 4V @ 250µA |
| Supplier Device Package | TO-263 (D2PAK) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Vgs (Max) | ±20V |
| Drain to Source Voltage (Vdss) | 100 V |
| Gate Charge (Qg) (Max) @ Vgs | 26 nC @ 10 V |
| Input Capacitance (Ciss) (Max) @ Vds | 670 pF @ 25 V |
